Q1. How do I install Remote Center?
|
- Sign onto work station as administrator.
- In the Control Panel window, double click display.
- Click the properties tab and move the Screen resolution
slider to the right to indicate the proper resolution of 1024 X 768 pixels.
- Click OK. Load installation CD and follow on screen instructions.
|
|
Q2. How do I update the DVR and Remote Center Software?
|
- On the DVR Main Control Panel screen, right click on the virtual power
(exit) button. A System Information window will appear.
- Click on the upgrade button, and the system will receive and install the latest version of our software.
Back to Top
|
|
Q3. How do I export video archives?
|
- In the DVR Main Control Panel window screen left click
on Search. The search window will appear.
- Towards the bottom left corner is a calendar. Select the date of the supposed event.
- Then by using the time table
blocks or the slide bar just below the blocks, start previewing the video for the
proper time frame of the incident you are searching. The controls on the right side
of the panel include regular speed view in forward and reverse, high speed review
in forward and reverse and frame by frame advance in forward and reverse.
- At this time note the start and stop time of the incident to calculate length of video
clip. Reset and pause video to start of incident.
- Click on Export Images button (with floppy disk symbol). The Export Images window will appear.
- Click on the AVI export file type then as an option you can click on Authentication Code. Click
on Set Password. Enter password in proper fields and click OK.
- Set the Export Length for the proper hours, minutes or seconds of the event then click on the specific
media you intend to save the file on, Floppy Disk, Network Drive, Thumb Drive, etc.
The Windows Save As dialog box will appear at which point you select the destination
of the file.
- If storage on a CD-RW type disk is required then load a disk and
click on the format CD button and then follow the same procedure done for the other media.
Note: For CD-R it usually takes about 1 minute to format while it requires up
to 30 minutes for a CD-RW to format. Therefore we recommend
CD-R for common back-up.
Back to Top
|
|
Q4. How do I set up a new user? |
SERVER
- In the Main Control Panel screen of the Server, click
User Admin. A dialog box with User Setup will display.
- Click on Add. Type in
User Name, user Description and password.
- In the Account Usage area of the dialog
box set the account for unlimited or limited (time settings). Also set the Authorized
Operations for Administrative, Search, PTZ, Remote Connection, Audio.
- Finally, select those cameras made available to that specific user by clicking on the required
numbered camera symbol at the bottom of the dialog window. Note that there is a
check box to enable Auto Login (unchecked requires user to enter password to log
on each time). Then click on Update.
WORKSTATION
- In the Main Control Panel screen
of the Remote Center workstation, click User Admin.
- A dialog box with User Profile
will display. Have the Site Name, User Name, IP/DNS Address and Router Port Number
at hand. Click on Add. Type in User Name and password and click OK. Then enter in
the Site Name, User Name, IP/DNS Address and Router Port Number. Note that there
is a check box to enable Auto Login (unchecked requires user to enter password to
log on each time).
- Then click on Update and OK.
Back to Top
|
|
Q5. How do I connect remotely?
|
- Assuming that the IT system administrator has enabled your workstation privileges
on the server and has added a user profile on the workstation with Site Name, User
Name, IP Address & Port Number, when the Remote Center software is enabled, the
Control Panel will display a split screen (with either static images or no images).
- On the right side of the control panel will be the Site List. Left click the
site you wish to view, left click to expand the device tree (showing all cameras
this workstation can view). If any camera symbols indicate an X within, right click
and choose show camera.
- Left click on site name again then click on connect button.
Back to Top
|
|
Q6. How do I use Instant Review?
|
- On the Server Control Panel, click on the Event button to display
event report.
- Expand the report chart by clicking the left arrow adjacent to
the chart.
- Scroll through the event log to search for the specific event you
want, right click on that event line and choose Instant Review from the menu. That
event will play on a pop-up window on screen.
- When finished, close that window
and click on the right arrow adjacent to the event log to minimize the event log.
Back to Top
|
|
Q7. How do I set up POS exception criteria?
|
- On the Server Control Panel click on the System Setup button.
- Click on the POS Interface tab to view the POS Interface Setup.
- Under "Exception" panel, click "Add" button to
add user-input texts, which will be displayed in the Exception Color specified by "Text Color" and an alarm will be generated for the corresponding camera.
- To delete items in the "Exception" panel, select the corresponding checkbox and
click "delete" button.
- Under "Exclude" panel, click "Add" button to add user-input text to the Exclude
list, which prevents a line containing the text from being displayed or recorded.
- To delete items in the "Exclude" panel, select the corresponding checkbox
and click "delete" button.
Back to Top
|
|
Q8. How can I Search an Event using keywords?
|
- On the Server Control Panel click on the Search button
- To the right of the
Recording Status grid are three buttons, choose event.
- In the Event Log, right
click on any line of the log.
- From the menu, choose Search.
- In the Search
Event dialog box, choose the range of dates, the Event Type, which camera inputs
and any text appropriate to your search such as "Refund >1.00". (Note: Search texts are case sensitive and must be consistent with the texts shown on POS/cash registers.)
- Click OK
- From the refreshed chart of search results left click on preferred file and use
the control to play the video clip.
Back to Top
|
|
Q9. How do I maximize and minimize windows in Remote Center?
|
- In the Server and Workstation Control Panel split screen left click on any camera
image to view a single camera (with controls remaining on screen).
- Right click
on that camera image and it will completely fill the monitor screen.
- To minimize
to screen with controls, right click on camera image.
- For split screen image,
left click on that image.
Back to Top
|
|
Q10. How do I add a second monitor or TV to the DVR (Dual Monitor Display)?
|
- Connect the monitor to the DVI or S-Video output on the video card
on the DVR and reboot the unit.
- Click on System Setup.
- Click on the General
setup button.
- In the System Setup & Maintenance section of the screen click the
Advanced button. That will take you into the Window user interface.
- Right click
anywhere on the desktop(except Icons) to bring up menu.
- If ATI Catalyst Control Center shows up in the context menu, please follow the following
procedure to set up the second monitor, otherwise go to step 7:
(a) Choose ATI Catalyst Control Center to bring up the ATI display settings window.
(b) Click on the third tab named “Profiles?to activate an appropriate profile from a list of pre-defined profiles:
Main Monitor Only - Default setting with only primary monitor in use.
Spot Monitor DFP - When a Digital Flat Panel (such as LCD) monitor is used as a spot monitor.
Spot Monitor CRT - When a CRT monitor is used as a spot monitor.
Clone Main CRT - When a CRT monitor is used to duplicate what the primary monitor displays.
Clone Main DFP - When a Digital Flat Panel (such as LCD) monitor is used to duplicate primary monitor display.
Spot Monitor (TV Only) - When a TV set is used as a spot monitor.
Double Up (TV Only) - When a TV set is used to duplicate what the primary monitor displays
(c) Click “OK" to quit from Catalyst Control Center and restart Windows.
- In case of no “ATI CATALYST Control Center" listed in the context menu when right-clicking on desktop, follow the steps below:
(a) Click on "Properties" to bring up "Display Properties" window.
(b) Click on Settings tab and choose the secondary monitor from the Display drop-down list.
(c) Select the checkbox "Extend my Windows desktop onto this monitor".
(d) Click OK to finish setup.
Back to Top
|
|
Q11. How do I connect to a DVR whose IP address is a dynamic IP address?
|
If a DVR user does not obtain from an ISP a static public IP address, the IP address he is assigned will be changing whenever the ISP changes it, therefore it is called an dynamic IP address. It is inconvenient for a DVR user to connect remotely to a DVR whose IP address is a dynamic IP address, because the user needs to know the exact IP address every time he attempts to connect.
The Dynamic DNS service provided by
www.DynDNS.com allows DVR users to alias a dynamic IP address to a static hostname in any of the many domains they offer, thus allowing DVR to be more easily accessed from various locations on the Internet by using the single static hostname.
The basic service (create
an account) is free of charge, however it requires users to keep service account active and otherwise inactive hosts will be removed from DynDNS.com after 35 days. To avoid this requirement, DVR users can buy an account upgrade.
Back to Top
|
|
Q12. How do I reach Sigmax for technical support?
|
- Call 713-779-8868 Monday through Friday 8:30AM - 5:30PM CST.
When you call, please have the Model number and Manual in hand. These items will
assist in getting the issue resolved in a quick and timely manner.
- Email
to support@sigmaxsecurity.com.
